YAG Energy Negative Feedback Laser Welder With High-Efficiency Fiber Laser Delivery
The YAG energy feedback laser welder uses advanced fiber transmission technology for efficient and stable laser output. The system supports both single-path and multi-path modes, allowing flexible energy distribution for different workpiece sizes and welding requirements. It seamlessly integrates with various workstations, including automated production lines, rotary platforms, and custom fixtures, offering versatility for both small batch and large-scale production.
Key Features
- High-Efficiency Fiber Laser Delivery with Multi-Path Capability.
- Optimized Optical System with Imported Quartz Components.
- High Damage Threshold and Stable Power Output.
- PID Adaptive Power Feedback for Consistent Welding.
- Wide Applications Across Precision Welding Industries.
Technical Specifications
| Model |
HW-Y-8 |
HW-Y-25 |
HW-Y-80 |
HW-Y-160 |
HW-Y-300 |
HW-Y-500 |
| Input Electric |
AC220 50/60 Hz |
AC220 50/60 Hz |
AC380 50/60 Hz |
AC380 50/60 Hz |
AC380 50/60 Hz |
AC380 50/60 Hz |
| Wavelength |
1064nm |
1064nm |
1064nm |
1064nm |
1064nm |
1064nm |
| Output Power |
8 W |
25 W |
80 W |
160 W |
300 W |
500 W |
| Pulse Energy |
5 J |
25 J |
50 J |
50 J |
70/100 J |
70/100 J |
| Pulse width |
15 ms |
15 ms |
15 ms |
15 ms |
15 ms |
15 ms |
| Frequency |
30 Hz |
30 Hz |
100 Hz |
100 Hz |
100 Hz |
100 Hz |
| Power Stability |
± 2.5 |
± 2.5 |
± 3.0 |
± 3.0 |
± 3.0 |
± 3.0 |
| Working Mode |
Pulse |
Pulse |
Pulse |
Pulse |
Pulse |
Pulse |
| Cooling mode |
Air |
Air |
Water |
Water |
Water |
Water |
| Weight |
100 Kg |
100 Kg |
170 Kg |
180 Kg |
220 Kg |
240 Kg |
| Equipment |
1 Kw |
1.2 Kw |
3 Kw |
6 Kw |
12 Kw |
16 Kw |
| Dimension |
955*415*870 mm |
1175mm*515mm*980mm |
1360mm*630mm*1120mm |
Applications
The integrated PID feedback technology automatically regulates laser power throughout the welding process. It maintains constant thermal input, ensuring each weld is uniform and defect-free. Whether performing precision micro-welding or multi-station continuous production, the system delivers consistent results from the first part to the last.
The YAG laser welder is ideal for fiber optic components, USB connectors, smartphone parts, 18650 battery caps and tabs, hardware components, kitchen and sanitary products, jewelry, elevator panels, home appliance metal parts, and motor components. Its high stability and precision make it suitable for industries that demand reliable, high-quality welding.
